Experience music like never before with the DS18 ZXI-574 - the perfect solution for audiophiles looking to elevate their car audio system’s sound quality. Designed to deliver powerful sound with minimal distortion, these speakers ensure an enhanced listening experience that will leave you wanting more.

The ZXI-574 features a Glass Fiber cone woofer with a rubber surround, the perfect combination for delivering precise and punchy bass responses. Combined with the rubber surround, the ZXI-574 reduces unwanted vibrations, resulting in cleaner and more accurate sound.

The 2-way design equips the 5 x 7 woofer with a 1-inch Neodymium Magnet Tweeter, which delivers unmatched clarity and detail in the higher end of the frequency range. Neodymium magnets, known for their lightweight and powerful properties, allow the speaker to reproduce accurate high frequencies without increasing the overall weight, resulting in a more balanced and natural sound.

With frequency responses ranging from 40Hz – 20KHz, the ZXI-574 is built to deliver clear and powerful sound across the entire frequency spectrum.

Key Features:

• Glass Fiber Cone Woofer: Delivers precise and punchy bass responses with minimal distortion.
• Rubber Surround: Reduces unwanted vibrations for cleaner sound.
• 1-inch Neodymium Magnet Tweeter: Provides unmatched clarity and detail in high frequencies.
• 2-Way Design: Ensures balanced and natural sound across all frequencies.
• Wide Frequency Response: 40Hz – 20KHz for clear and powerful sound.

Technical Data:

• SKU: ZXI-574
• Nominal Diameter: 5 x 7 Inches
• Nominal Impedance: 4 ohm
• RMS Power Handling: 70 WATTS
• MAX Power Handling: 210 WATTS
• Sensitivity: 91 dB
• Frequency Response: 40 Hz - 20 KHz
• Recommended Hi Pass: 60 Hz
• Speaker Type: 2-Way

Midrange Specifications:

• Voice Coil Diameter: 25.5 mm (1 inch)
• Voice Coil Former Material: KSV
• Winding Material: EISV
• Cone Material: Glass fiber
• Surround Material: Rubber
• Basket Material: Steel
• Magnet Material: Barium Ferrite
• Magnet Weight: 14.46 oz / 410 g

Tweeter Specifications:

• Nominal Diameter: 25.4 mm (1 inch)
• Voice Coil Diameter: 20.4 mm (0.8 inch)
• Voice Coil Former Material: KSV
• Winding Material: EISVM
• Diaphragm Material: PEI
• Magnet Material: Neodymium
• Magnet Weight: 8.5 g / 0.3 oz

Thiele & Small Parameters:

• Vas: 8.66 LTR
• Xmax: 2.7 mm
• Fs: 68 Hz
• Qms: 7.04
• Qes: 1.28
• Qts: 1.08
• Mms: 16.1 g
• Cms: 258.7 mm / N
• BL: 4.66
• Le: 228 mH
• Sd: 153.5 cm²
• Re: 3.5 ohm
• Mmd: 14 g

Measurements:

• Overall Diameter: 5.55 x 7.60 inch (141 x 193 mm)
• Overall Depth: 72 mm (2.84 inch)
• Front Mount Baffle Cutout: 125 x 179.5 mm (4.92 x 7.07 inch)
• Mounting Depth: 56.5 mm (2.22 inch)
• Motor Diameter: 94 mm (3.70 inch)
• Product Weight: 6 lbs
• Product Dimensions: 14 x 9.5 x 3.75 inches

The DS18 ZXI-574 5x7 2-way Coaxial Speakers with Glass Fiber Cone are designed to deliver powerful, distortion-free sound with enhanced bass responses and unmatched high-frequency clarity. Upgrade your car audio system with these durable and high-performance speakers to enjoy a premium listening experience.
