DS18 Compact 1 Channel Monoblock Amplifier Class D X1

Amazing power and an amazingly small footprint are what the DS18 X1 amp is all about. This tiny amp packs a powerful punch all while fitting in the palm of your hand! It is a perfect selection for audiophiles cramming audio in tight spaces. For example, you can fit multiple X series amps in most motorcycle fairings powering an entire system all while safely tucked away. Small enough to fit in your hand but powerful enough to power four high-powered speakers, this Bass amp little powerhouse pumps out 140 watts RMS at 4 ohms and 220 at 2 ohms, and 300 watts RMS at 1 ohm making it perfect for a small single sub. which is enough to get super loud sound with great clarity.

Features

• CLASS CLASS-D
• Channels 1
• Total watts (PEAK) 900W
• RMS Power @ 4 OHM 140W x 1CH
• RMS Power @ 2 OHM 220W x 1CH
• RMS Power @ 1 OHM 300 x 1CH
• RMS Power @ 4 OHM BRIDGE -
• Frequency response 20Hz-500Hz
• Signel/Noise Ratio >90 dB
• Efficiency @ 4 OHM >80%
• Damping Factor >200
• THD % <0.2%
• Low-level input range 0.2-5V
• Selectable X-Over FIXED LPF
• X-OVER filter range 50Hz-250Hz
• Bass boost range 0-18 dB
• Bass boost frequency 40Hz
• Infrasonic filter 10-55Hz
• Phase selector 0 - 180 DEGREES
• Minimum impedance 1 OHM
• LED Indicator POWER/PROTECTION
• Power input size 12GA
• Fuse rating 30A
• Remote level control YES - Dash mount
• Thermal protection YES
• Overload protection YES
• DC output protection YES
• Short circuit output protection voltage input protection YES
• Voltage input protection YES
• Dimensions LxWxH (INCHES) 5.54 x 3.24 x 1.37"
• Heatsink length 4.75"
• Easy installation
• Stable/reliable four layers traces PCB design YES
• Surface mount component technology YES
• Audio precision quality control verification YES
• Configuration 2CH/4CH input selector NO
