Diamond Audio Monoblock Digital Amplifier HXM1200.1D

This amplifier is manufactured by Diamond Audio made to operate at a total power of 1200 Watts Max and crafted with the best components on the market. It has a high-density aluminum alloy heat sink with a backlit logo bringing you style and longevity in a compact system. With a BTR port, it gives you the option to control it via Bluetooth and integrated soft clip light for quick system set-up.

Specifications

• MOTORSPORT-Series 1200W RMS Class-D Monoblock Motorsport/ATV/Marine/UTV Amplifier
• RMS Power Rating: 1 Ohm: 1200 Watts x 1 Channel, 2 Ohm: 850 Watts x 1 Channel, 4 Ohm: 550 Watts x 1 Channel
• Signal to Noise Ratio: 97.4 dB
• Variable Low-Pass 30 Hz - 300 Hz
• Variable Sub-Sonic 10 Hz - 55 Hz
• Dimensions: 11.72"(L) x 5.27"(W) x 1.75"(H)
• Ultra-Compact, High Density Aluminum Alloy Chassis Provides Superior Thermal Stability
• Four Layer, Glass Epoxy Circuit Board For Enhanced Performance & Reliability
• Circuit Board Conformal Coated
• Balanced Differential Inputs For Superior Noise Rejection
• Fully Variable, 12 dB/Octave, Electronic Crossover
• Top-Mounted Controls For Convenient Adjustment
• Integrated Soft Clip Light
• Illuminated Logo
