PRV Audio 12" Mid Bass Loudspeaker 8 Ohms 12MB1000FT

For high output speaker systems, PRV Audio’s 12MB1000FT mid bass is an excellent option capable of amazing performance. A great new addition to the Forte Series, where more power handling and less distortion on mid low mid bass frequencies is the key. All this attention to detail the 12MB1000FT makes it one impressive driver. With 97.5 dB efficiency and 1000 watts max power handling this mid bass will be ideally used in stage monitor, auditorium, touring and outdoor systems. The smooth response from 70 to 3,200 Hz is perfect for 2 or 3-way designs.

Features

• 3″ Inside/Out aluminum voice coil wound on fiberglass former for hi-temp performance, 8 ohms
• Ventilated voice coil gap reduces power compression
• High Xmax for more Mid bass output
• Excellent performance in 2-way or 3-way systems
• Weather-resistant paper cone and dust cap
• Nominal Diameter: 12″ (310 mm)
• Nominal impedance: 8 Ohms
• Rated AES Power Handling (RMS): 500 Watts
• Program Power: 1000 Watts
• Sensitivity 2.83V at 1m: 97.5 dB
• Frequency Response at -10dB: 70 – 3,200 Hz
• Voice Coil Diameter: 3″ (75 mm)
• Voice Coil Wire: Aluminum
• Voice Coil Winding Depth: 19.0 mm
• Former Material: Glass Fiber
• Magnetic Gap Depth: 10.5 mm
• Frame Material: Die Cast Aluminum
• Overall Diameter: 12.48”(317 mm)
• Front Mount Baffle Cutout: 11.16” (283.5 mm)
• Mounting Depth: 5.20”(132 mm)
• Overall Depth: 5.76”(146.5 mm)
