PRV Audio 8" Mid Bass Speaker 700W Max Power 4 Ohm Forte Series 8MB700FT-NDY-4 PRV Audio 8" Mid Bass Speaker 700W Max Power 4 Ohm Forte Series 8MB700FT-NDY-4
PRV Audio 8" Mid Bass Loudspeaker 4 Ohm 8MB700FT-NDY-4
The 8MB700FT-NDY-4 is an extremely efficient 8″ mid-bass from PRV Audio. This driver is perfect for mating to compression drivers due to its wide frequency bandwidth and its high 98 dB sensitivity rating on a 3-way system. To get superior fidelity, the special composite cone is built with non-pressed paper for a reduced break-up, delivering a smooth frequency response and a low moving mass, increasing the efficiency of the speaker.
Features
• Nominal Diameter 8″ (203 mm)
• Nominal impedance 4 Ohms
• Rated AES Power Handling (RMS) 350 Watts
• Program Power 700 Watts
• Sensitivity 2.83V at 1m 98 dB
• Frequency Response at -10dB 70 – 5,600 Hz
• Voice Coil Diameter 2.5″ (63 mm)
• Voice Coil Wire CCAW
• Voice Coil Winding Depth 11.5 mm
• Former Material Fiber Glass
• Magnetic Gap Depth 8.00 mm
• Frame Material Die Cast Aluminum
• Equivalent Volume Vas 24.97
• Excursion (mathematical)*** Xmax 3.75 mm
• Free Air Resonance Fs 59.6 Hz
• Mechanical Factor Qms 3.81
• Electrical Factor Qes 0.24
• Total Factor Qts 0.22
• Cone Area Sd 249 cm²
• Mechanical Mass Mms 24.67 g
• Bl Factor Bl 11.30 Tm
• Dc Resistance Re 3.3 Ohms
• Inductance Le 0.266 mH at 1 kHz
• Mechanical Mass Without Air Mmd 22.45 g
• Mechanical Compliance Cms 0.288 mm/N
• Overall Diameter 8.20” (208.5 mm)
• Front Mount Baffle Cutout 7.30” (185.5 mm)
• Mounting Depth 3.66” (93 mm)
• Overall Depth 4.00” (101.5 mm)
• Net Weight 4.32 Lbs (1.96 kg)
• Shipping Weight 5.51 Lbs (2.50 kg)
• Carton Dimensions W x L x H 9.05” x 9.05” x 5.11” (230 x 230 x 130 mm)
