Black Diamond 12" Subwoofer 1200 Watts Dual 2 Ohm Car Audio DIA-R12D2 Single
Click to enlarge

Black Diamond 12" Subwoofer 1200 Watts Dual 2 Ohm Car Audio DIA-R12D2 Single Black Diamond 12" Subwoofer 1200 Watts Dual 2 Ohm Car Audio DIA-R12D2 Single

$109.99 $119.95

Black Diamond 12" Subwoofer with Dual 2 Ohm VC DIA-R12D2

This Black Diamond DIA-R12D2 delivers an impressive 1200W Max Power with 600W RMS at Dual 2+2 Ohm. Once you hear it, you will finally realize what big, rich bass sounds like. The R12D2 provides multiple options and flexibility to wire Parallel, Series, or Independent. Settle for nothing but the best with Ferrite magnets that produce a wider range of tones and can handle tremendous power at high volumes. This ultra-reliable subwoofer has dual voice coils, Kevlar dust cap, and foam edges all at an affordable price.

Features

• Nominal Diameter: 12" / 304mm
• Nominal Impedance: 2+2 OHMS
• RMS Power Handling: 600 Watts
• MAX Power Handling: 1200 Watts
• Sensitivity (1w/1m): 85.5dB
• Frequency Response:20-300Hz
• Recommended Lo Pass Crossover:80Hz
• Voice Coil Diameter: 2.5" / 63.5mm
• Voice Coil Former Material: Aluminum
• Winding Material: CCAW
• Cone Material: Paper
• Dust Cap: Paper
• Surround Material: Foam
• Basket Material / Material de la Canasta: Steel
• Basket Color - Finish: Black
• Magnet Material: Ferrite
• Magnet Weight: 100 oz
• Displacement Volume: 1.9L / 0.07ft3
• Equivalent Volume: 33.79L / 1.19ft3
• Excursion (one way): 13.5mm
• Free Air Resonance: 33Hz
• Mechanical Factor: 3
• Electrical Factor: 0.562
• Total Factor: 0.473
• Moving Mass: 259.7g
• Compliance: 0.108 mm/N
• Bl Factor: 17.717
• Voice Coil Inductance: 0.410mH
• Diaphragm Area: 471.25 cm2
• Dc Resistance: 1.8 + 1.8 ohm
• Efficiency Bandwith Product: 58.7
• Overall Diameter:12.6" / 320mm
• Overall Depth: 7.75" / 197mm
• Front Mount Baffle Cutout: 10.86" / 276mm
• Mounting Depth: 6.6" / 168mm
• Motor Diameter: 6.14" / 156mm
