DS18 15" High Excursion Subwoofer DVC 4 Ohm GEN-XX15.4DHE

High excursion is now the mainstream and usually, this feature is very expensive, and enthusiasts sometimes miss out on amazing bass because of the large cost. We want to bring the experience of low-frequency bass to even the entry-level user. The GEN-XX15.4DHE is the answer to that issue. This subwoofer is a mid-tier addition that comes in at an amazing price point while getting all those features other much more expensive high excursion subs to come with.
Also, with a power rating of 550w RMS and 1100w Max, this sub does not require large amounts of power to come alive and beat up the block.

Features

• High Excursion surround for a very high amount of xmax.
• Great power handling of 550w RMS and 1100w max.
• Long three voice coil and extended magnet to accommodate the xmax increase.
• FS of 30 Hz so you can easily dip in the subsonic range with no issues along as your box is tuned correctly.
• Nominal Diameter: 15"
• Nominal Impedance: 4+4 ohms
• RMS Power Handling: 550W
• MAX Power Handling: 1100W
• Sensitivity (1w/1m): 87.4 dB
• Frequency Response: 20Hz - 1KHz
• Recommended Lo Pass Crossover: 80Hz
• VC Diameter: 2
• VC Former Material: Black Aluminum
• Winding Material: SV
• Cone: Material Paper
• Dust Cap Material: PPI
• Surround Material: Foam
• Basket Material: Steel
• Basket Color/Finish: Glossy Red
• Magnet Material: Ferrite
• Magnet Weight: 136 Oz
• Displacement Volume: 3.26L
• Equivalent Vol: Vas 105.083L
• Excursion (one way) Xmax: 25 mm
• Free Air Resonance: Fs 27 Hz
• Mechanical Factor Qms: 3.658
• Electrical Factor Qes: 0.583
• Total Factor Qts: 0.503
• Mechanical Mass Mms: 309.67g
• Mechanical Compliance Cms: 0.112mm/N
• Bl Factor: BL 24.045 N/A
• VC Inductance: Le 0.6741mH
• Cone Area: Sd 814.332cm2
• Dc Resistance: Re 3.2+3.2 ohms
• Efficiency Bandwidth Product: EBP 46.3
• Overall Diameter: 15.5" / 394 mm
• Overall Depth: 9.06" / 230 mm
• Front Mount Baffle Cutout: 13.98" / 355 mm
• Mounting Depth: 7.84" / 199mm
• Motor Diameter: 6.15" / 156mm
