DS18 8" Subwoofer Dual 2 Ohm 900W Max 450W RMS Elite Z Series ZR8.2D Single
Click to enlarge

DS18 8" Subwoofer Dual 2 Ohm 900W Max 450W RMS Elite Z Series ZR8.2D Single DS18 8" Subwoofer Dual 2 Ohm 900W Max 450W RMS Elite Z Series ZR8.2D Single

$89.96 $109.95

DS18 8" Subwoofer DVC 2 Ohm Elite Z Series ZR8.2D

The ZR subline is a great entry level subwoofer that both handles great power and gives you smooth clean bass. These subs work great in both sealed and ported boxes giving you many options for placement in any vehicle. This 8 inch model comes in both dual 2 and dual 4 ohm configurations giving you many options to match your amplifiers optimal impedance. This model comes with a 2 inch voice coil that handles 450W RMS and 900w max power. The large foam surround and pressed paper cone works greatly together to deliver smooth crisp bass that can be heard strongly throughout the vehicle.

Features

• Large foam surround giving great xmax and bass precision while keeping great cone control when the subwoofer is close to maximum power.
• Great power handling of 450w RMS and 900w max through a high strength 2 inch aluminum voice coil.
• Very strong stamped basket with show quality DS18 logos on the frame, magnet boot, motor, and dust cap.
• Designed to give crisp and clear bass in any vehicle and can be used in sealed and ported boxes.

Specifications

• Nominal Diameter 8”
• Nominal Impedance 2+2 OHMS
• RMS Power Handling 450W
• MAX Power Handling 900W
• Sensitivity (1w/1m) 82 dB
• Frequency Response 33Hz - 200 Hz
• Recommended Lo Pass Crossover 120 Hz
• Voice Coil Diameter 2” / 50.8mm
• VC Former Material Aluminum
• Winding Material Copper
• Cone Material Non Pressed Paper
• Dust Cap Material PPI
• Surround Material Foam
• Basket Material Steel
• Basket Color/Finish Matte Black
• Magnet Material Ferrite
• Magnet Weight 55 oz
• Displacement Volume 0.03 ft3
• Equivalent Volume 5.74 L
• Excursion (one way) 18mm
• Free Air Resonance 40Hz
• Mechanical Factor 4.38
• Electrical Factor 0.66
• Total Factor 0.57
• Moving Mass 112.72g
• Compliance 105.133 m/N
• BL Factor 6.67
• Voice Coil Inductance .373.76m mH
• Cone Area 196 Cm2
• DC Resistance 1.8 + 1.8 ohm
• Efficiency Bandwidth Product 60.6
• Overall Diameter 8.42” / 214mm
• Overall Depth 5.3” / 134mm
• Front Mount Baffle Cutout 7.24” / 184mm
• Mounting Depth 4.4” / 111.4mm
• Motor Diameter 5.7" / 145mm
